| CARRIER ENGINE | ||
| Make | Mitsubishi | |
| Model | 6D22-1A | |
| Gross Power | 221.3 hp | 165 kw |
| Power Measured @ | 2200 rpm | |
| Max Torque | 563.5 lb ft | 764 Nm |
| Torque Measured @ | 1400 rpm | |
| Displacement | 680.4 cu in | 11.1 L |
| Operational | ||
| Operating Weight | 54233.7 lb | 24600 kg |
| Carrier Fuel Capacity | 52.8 gal | 200 L |
| Upper Structure Hydraulic System Fluid Capacity | 100.4 gal | 380 L |
| Operating Voltage | 24 V | |
| Tire Size | 11.00-20-14PR | |
| Transmission | ||
| Type | synchromesh and constantmesh gear | |
| Number of Forward Gears | 5 | |
| Number of Reverse Gears | 1 | |
| Max Speed - Forward | 40.4 mph | 65 km/h |
| Boom | ||
| Number of Sections | 4 | |
| Min Height @ Max Raise Angle | 39.4 ft in | 12 m |
| Max Height @ Max Raise Angle - no jib | 108.3 ft in | 33 m |
| Max Elevating Angle | 80 degrees | |
| Max Lift Capacity | 55115.6 lb | 25000 kg |
| Min Working Radius | 8.2 ft in | 2.5 m |
| Max Working Radius | 96.1 ft in | 29.3 m |
| Swing Speed | 2.6 rpm | |
| Dimensions | ||
| Transport Length | 39.1 ft in | 11930 mm |
| Transport Width | 8.2 ft in | 2500 mm |
| Transport Height | 10.8 ft in | 3300 mm |
| Width w/ Outriggers Extended | 19.7 ft in | 6000 mm |
| Upper Structure Tail Swing Radius | 10.6 ft in | 3240 mm |
