| Engine | ||
| Make | Caterpillar | |
| Model | C4.4 ACERT | |
| Gross Power | 100 hp | 74.5 kw |
| Net Power | 96 hp | 71.6 kw |
| Power Measured @ | 1900 rpm | |
| Displacement | 268.5 cu in | 4.4 L |
| Number of Cylinders | 4 | |
| Operational | ||
| Operating Weight | 20741 lb | 9408 kg |
| Fuel Capacity | 51.5 gal | 195 L |
| Cooling System Fluid Capacity | 5.9 gal | 22.4 L |
| Engine Oil Capacity | 2.9 gal | 11 L |
| Hydraulic Fluid Capacity | 15.7 gal | 59.5 L |
| Final Drives Fluid Capacity | 2.6 gal | 10 L |
| Operating Voltage | 12 V | |
| Alternator Supplied Amperage | 120 amps | |
| Transmission | ||
| Type | Hydrostatic | |
| Max Speed - Forward | 5.6 mph | 9 km/h |
| Max Speed - Reverse | 6.2 mph | 10 km/h |
| Undercarriage | ||
| Ground Pressure | 5.7 psi | 39.1 kPa |
| Ground Contact Area | 3652 in2 | 2.4 m2 |
| Standard Shoe Size | 20 in | 510 mm |
| Number of Shoes per Side | 40 | |
| Number of Track Rollers per Side | 7 | |
| Track Gauge | 5.2 ft in | 1600 mm |
| Hydraulic System | ||
| Relief Valve Pressure | 2988 psi | 20600 kPa |
| Pump Flow Capacity | 19.4 gal/min | 73.5 L/min |
| Standard Blade | ||
| Width | 9.5 ft in | 2886 mm |
| Height | 41.3 in | 1050 mm |
| Capacity | 2.9 yd3 | 2.2 m3 |
| Blade Angle (both directions) | 25 degrees | |
| Cutting Depth | 23.1 in | 586 mm |
| Dimensions | ||
| Length w/o Blade | 10.7 ft in | 3265 mm |
| Width Over Tracks | 6.9 ft in | 2110 mm |
| Height to Top of Cab | 8.9 ft in | 2722 mm |
| Length of Track on Ground | 7.6 ft in | 2310 mm |
| Ground Clearance | 1.1 ft in | 332 mm |
